AC 220V 120W Gear Reducer Motor High Torque 22RPM & AC Speed Controller Kits for Industry

Rated Voltage: 220V; Power:120W; No-load Speed: 22RPM; Rated Torque: 40.9N.M; Gear Reduction Ratio:5GU60K; Shaft Diameter: 15mm; Frequency: 50HZ/60HZ; Pls confirm the dimenssions in the pictures;Due to we don't have enough room to display all the speed options of this motor, please contact us if you need other speed, we can customize it, thanks!

• ✔Rated Voltage: 220V; Power: 120W; No-load No-load Speed: 22rpm(50HZ)/28rpm(60HZ); Max Rated Torque: 441lb.in(50HZ)/362lb.in(60HZ); Gear Reduction Ratio: 5GU60K;Shaft Diameter: 15mm; Approximate Dimensions: 10.9*3.55*3.55 in(L*W*H) include shaft;
• ✔Controller safety range: If the motor load is small and not operated for a long time, the controller can be adjusted to 35% of the full speed. When motor load and work continuously for a long time. the controller shouldn't be lower than 72% of the full speed, because motor is slowed down by reducing volt, after volt is reduced, the torque will also become smaller, it may overload; at this time, due to the increase of current, the heat dissipation will become worse, motor will heat up seriously;
• ✔Quality Guarantee: Under normal usage and without overloading, One year motor warranty; If you chose the wrong speed, you can contact us for replacement, and all problems pls send us e-mail firstly, we will give you satisfactory solution, pls trust our brand "BEMONOC" and give us the chance, thanks!
• ✔Package: 1PCS x One-phase Adjustable Motor AC 220V 120W adjustable motor + 1PCS 120W 220V Speed Governor + 1PCS Wiring instructions; (If you don't need speed controller, contact us to minus price);
• ✔Widely used in packaging, printing, textile, dyeing, chemical, food, medical, pharmaceutical construction machineries. And advertising, office, petrochemical, instrumentation, stage lighting, transmission, automatic warehouse, parking access control system and other equipments.
